SHARK S4 PLUS

4-CH SDI/HDMI VIDEO SWITCHER

  • 10.1 inch FHD IPS LCD display
  • 2×HDMI & 2×3G-SDI inputs, support auto-detected
  • 2×HDMI PGM output,1×HDMI multiview out, 1×USB type-C output
  • RTMP/SRT stream & USB disk/ SD card record
  • AUX output configurable and assignable
  • USB for capturing and streaming on PC
  • Upstream key: Luma key, Chroma key, PIP×2/ POP
  • Downstream key and LOGO overlay
  • T-bar/ Auto/ Cut transitions; various effects: WIPE(11×3patterns) / MIX/ DIP
  • Audio mixer: 2×HDMI, 2×SDI embedded audio and 2-Ch MIC/line in; audio delay available
  • Media library: 39 default patterns, 16 imported images, 16 captured images, 2 color generators
  • Customer configuration import andexport
  • FTB/ MUTE/ STILL/ GPIO for tally
